Energy and Power Equipment Field Forged Gears Discs

Energy and Power Equipment Field Forged Gears Discs

Application scenarios: Low-speed stage gears of large wind turbine gearboxes (onshore/offshore wind power), reduction gears of hydropower generating units, transmission gears of thermal power steam turbines, etc.
Working conditions: Wind power gears need to withstand alternating loads and low temperatures (in northern wind power projects); their size increases with power (the diameter of gears for models above 5MW can reach more than 3 meters); hydropower gears need to adapt to humid environments.

Contact Us
  • Performance Requirements
  • Advantages
Performance Requirements

Commonly used materials:
20CrMnMo: After carburizing, its surface hardness reaches HRC58-62, with good core toughness. It is wear-resistant and resistant to alternating loads, suitable for gears of wind power gearboxes.
4140/EN19/42CrMo4: It has high strength after quenching and tempering and stable mechanical properties, adapting to long-term high-load operation of equipment such as wind power and thermal power units.
0Cr13Ni5Mo (stainless steel): It has good corrosion resistance and is used in parts of water turbine gears that come into contact with water.

Material Heat Treatment Key Characteristics Typical Applications
20CrMnMo Carburizing Surface hardness HRC 58-62, good core toughness, wear-resistant, resistant to alternating loads Gears of wind power gearboxes
4140 / EN19 / 42CrMo4 Quenching and Tempering High strength, stable mechanical properties, adapts to long-term high-load operation Gears for wind power and thermal power units
0Cr13Ni5Mo - Good corrosion resistance Parts of the water turbine gears are in contact with water
